Banner Thermoplastic 150 M Range Opposed Mode Barrel Receiver Sensor for S30 Series

Banner Thermoplastic 150 M Range Opposed Mode Barrel Receiver Sensor for S30 Series

Brand: Banner

Housing Material: Thermoplastic

Connection Type: Cable

Cable Length: 9 m

Sensing Mode: Receiver

Min Operating Temperature: -40ºC

Max Operating Temperature: 70ºC

Sensing Range: 150000 mm

Supply Voltage: 10-30V dc

Max Operating Relative Humidity: 90% at 50ºC

Lens Material: Acrylic

Barrel Diameter: 30 mm

Output Response Time: 10 ms

Number of Pins: 4

Sensing Beam: Infrared LED

IP Rating: IP67

Indicator: LEDs

Housing Style: Barrel

Operation: Light/ Dark Operate

Outputs: NPN/ PNP
